Spine Line Analysis

Spine Line Corridor
Source: PAT

"The Spine Line" Corridor Study, which was conducted in 1992 and published in 1993, explores alternatives to traffic congestion in Pittsburgh's main corridor, focusing mainly on 3 light rail designs that would extend the city's current LRT system. The area studied is the most developed area of Pittsburgh, extending east from Downtown, through the Hill District, Oakland and terminating at Squirrel Hill. There were "114,000 residents and over 229,000 jobs located in this corridor" in 1993 and the highest volumes of Pittsburgh Port Authority (PAT) riders, "115,000 of the 285,000 weekday riders" began or ended their commute within this area. The study explored a wide range of environmental impacts including land use, economic, displacements and relocations, neighborhood character, visual and aesthetic qualities, air quality, noise, ecosystems, wetlands, water resources, utilities, historical and archaeological sites, resources, and parklands.


Three main alternatives were explored for extension of the LRT system from downtown to Oakland:
-the Center Avenue Ave. Alternative
-The Colwell Alternative
-The Technology Center Alternative
All of these alternatives would connect to the Squirrel Hill Extension

LRT Alternatives
Source: Modified PAT image

The report describes each alternative as follows:

The Centre Avenue Alternative-  would have its junction with the existing "T" at the Manor Building and would be constructed as a subway for its entire length. The line would curve and follow Centre Avenue to Soho Street. It then would turn southeast to enter Oakland at Craft Avenue. Stations Nould be located at the Civic Arena, Dinwiddie Street, and Soho Street near Kirkpatrick.

The Colwell Alternative- would also connect with the "T" at the Manor Building. It could be built either at-grade or in a subway configuration along Colwell Street parallel to Fifth Avenue through the Hill.and Midtowncommunities. Stations would be located at the Central Medical Center and Hospital near the Civic Arena, at Dinwiddie Street and at Kirkpatrick Street.

The Technology Center Alternative- would have its junction with the "T" at the site of the former B & 0 Railroad Passenger Terminal and be constructed at-grade to the Pittsburgh Technology Center where it would rise up over the Parkway East before entering Oakland. Stations would be located by Duquesne University and at the Pittsburgh Technology Center. This alternative would also serve the proposed First Avenue station, which may be built even without the Spine Line

The Squirrel Hill extension.-It would be built in a subway configuration under Forbes Avenue from Morewood to its terminus east of Dallas Avenue. Stations would be located at Murray Avenue and adjacent to the Homewood Cemetery across Forbes Avenue from Frick Park.

These schemes generally were not expected to alter land-use or economic patterns within the study area. They also wouldn't have displaced a great number of residents or businesses. "The Technology Center Alternative would require the fewest displacements, with just two businesses affected. The Centre Avenue Alternative would displace 9 residences and 5 commercial uses. The Colwell Alternative would require relocation of 52 residences and 5 commercial structures." However, according to the study, there is more than adequate replacement housing and commercial building sites. Additionally, the schemes would offer no permanent loss of parklands.

I have found two designers, Craig Toocheck and Edward Shin, who have created informal schemes for LRT extensions for Pittsburgh in recent years. Craig Toocheck, a Catholic University Architecture Alumus, has a scheme that combines the Colwell and Centre Ave schemes. The yellow line from downtown eastward is his version of the "Spine Line." It has many stops along this corridor and in my opinion would be best to combine a local and express trains along its length.

LRT Concept Map
Source: Toocheck

Shin, designer of Extra Cogent, has developed a map with far fewer stops. The equivalent of the "Spine Line" on his map includes two lines, the purple and green, which have stops at Mellon Arena, CMU, Pitt, Duquesne and Oakland. His scheme roughly includes both the Technology Center Alternative and one stop on the Colwell or Centre Ave Alternatives.

LRT Concept Map
Source: Extra Cogent

The main difference between the schemes outlined in the "Spine Line" Study, besides which streets to follow, is the grade level of the tracks. The Colwell and Technology Center schemes deal mainly with at-grade tracks while the Center Ave scheme is below-grade for the majority of the scheme. The choice between at-grade and below-grade greatly affects the cost of the scheme as well as its presence in the city. The study calls this presence  "Visual Impact" and describes the consequences of the different lines:
 "The Colwell at-grade Alternative would be visible along Colwell Street and in the vicinity of Dinwiddie and Kirkpatrick Streets. The Technology Center Alternative would be visible along the Monongahela River segment, mostly in an existing railroad right-of-way where it would constitute no significant change. As that alignment rises onto aerial structure to cross the Parkway East, the bridge would be visible from that highway and Second Avenue, but would be isolated from sensitive uses and would be but one more of a series of bridges crossing over those roadways."


The "Visual Impact," or physical presence, is a critical architectural aspect of any new LRT within the city. It can attempt to blend in with its surroundings or stand out. If the city plans on celebrating the new LRT or BRT system that it builds, it "visual impact" must be positive on the city. The question is if at- or above-grade  designs, which are far cheaper, can actually greater serve the city's image. It is possible that a more visible system would better portray Pittsburgh's image as a modern city. As long as the at-grade lines don't sever the neighborhoods they passed through or obstructed traffic, they could potentially greater serve the city with a more dominant presence. (By no means am I suggesting building all of the lines above grade, but I am suggesting using this in key spots to "show off" the city's technology).


Much like designers Toocheck and Shin, I believe that having only one line run through the Spine Line corridor might be a mistake. This study was developed in 1993 and was not intended to be a complete comprehensive LRT system. If I am going to be examining this corridor as part of a greater citywide network, then many more factors will arise when designing this line and adjacent lines together. That said, it is true that the all three of these alternatives (Colwell, Tech Center and Centre Ave) are the major corridors within the larger district of the city and that ideally there would be lines running along all of these routes. However, if I were to choose which institutions to include in the Spine Line, I would prioritize Duquesne University, Consol Center (new home of the Penguins), UPitt and CMU, with the residential neighborhoods in the area being the second highest priority.


Sources:
Spine Line Corridor Study http://www.briem.com/files/spineline1993.pdf
Extra Cogent http://www.extracogent.com/
Craig Toocheck Maps http://www.behance.net/gallery/Transit-maps/1179833

Terminal, Threshold and Rebirth

The Birth of Venus

Sandro Botticelli 1482-6

After recently riding various subways, I began to feel more than ever that exiting underground stations is a very powerful event. Crossing the below/above ground threshold strongly foments most of our senses. The artificial lights of the underground give way to daylight. The sheltered and controlled environment below gives way to natural fluctuations of weather. Wind and rain or heat or cold.  Sounds change. Smells too.  Suddenly, our intimate and protective surroundings, give way to a much more spacious and volatile world. I believe that crossing this threshold is as close to a rebirthing experience as we get in contemporary urban life.

The physical motion too is similar to being born. As this diagram shows, when we enter the world above, our heads is first revealed and then slowly working down to our feet, the rest of our bodies become exposed. This phenomenon is reciprocal. When exiting the underground, our line of sight starts at the top. The sky is first revealed to us, then the tops of our surroundings, working down to the ground. To the passenger, his surroundings too are being born.

Birth to Highline

Ben Samson 2011

This series of pictures from my visit to the Highline demonstrate such a vertical threshold. Here, at first nothing but a bright dot at the end of the stairs can be seen of the world above. As we move upwards, the surroundings are revealed from the sky downward. Finally, when we reach the final step, we become a part of this elevated world.

When thinking of this above/below ground threshold as rebirth, it induces many design questions. It seems that there is real opportunity to create some significant sensory experience. Should this transition be amplified or depressed? How should the design manipulate the senses? Conversely, being born in this process also suggests that traveling underground is somehow related to being encased by a womb. Eero Saarinen tried to capture the comfort and protection of a womb in his famous Womb Chair. Should the designs of the cars and underground spaces reflect this maternal peacefulness? Additionally, when we enter the world aboveground at a station, (especially for the first time) we are often disoriented and estranged, much like a newborn. Should there be orienting devices in place? And perhaps most importantly, because this threshold gives us a first impression of the surroundings of the area, how should this new world present itself?

Fetus
Yana P. Yaseva

Womb Chair
Eero Saarinen

Highline Park

Highline in use

Highline.org

This past weekend, I visited NYC, the transportation capital of America. Because of New York’s extreme density and concentration of humanity, the city has so many unique situations and opportunities to build upon itself. The Highline is one example where designers have found potential within the concrete jungle to do something unique and groundbreaking. Utilizing industrial remnants, the Highline Park has been a large part of the transformation of surrounding neighborhoods, Chelsea and The West Village, sprouting development and artwork all along its 1.5mile length. It is acting as a beacon of green design and offers a solution to how we repopulate our urban areas with good contemporary design while also maintaining the history and sense of place of the area. The Highline serves as a valuable example as I study the ideas of transforming the image of a city.

An Industrial Past

Highline.org

Originally, the above-grade tracks were built between 1929 and 1934, in order to reduce the number of crashes between trains, cars and pedestrians. This itself was a major transformation, as the surrounding Lower West Side was known as “Death Avenue” before the grade change. Trains regularly ran here until the early 1960’s and the last train rode ran in the 1980’s. Soon, there was no action on the tracks and wildlife began to sprout. Called a “self-sown landscape,” the Highline was both an eyesore and intriguing. Half ghost town, half meditation garden, The abandoned tracks sat quietly with the Empire State Building and other skyscrapers as a backdrop. In 2000, threatened with demolition, many local artists advocated preserving the landscape, and in 2004, a competition was held for redesign of the highline. Over the next 7 years, two sections of the park have been opened and the third and final section is underway.

Self-Sown Landscape

Joel Sternfield

Overgrown Tracks

Barry Munger

According to “Designing the Highline,” the park followed eight design principles:

1.    Keep it simple. Keep it wild. Keep it Quiet. Keep it Slow.

2.   Preserve typical railings and upgrade to fulfill code and ensure safety.

3.   Preserve North-South sight lines and linear consistency.

4.   Preserve slow meandering experience through varied conditions.

5.   Preserve and reveal the structure providing opportunities to inhabit and appreciate details.

6.   Preserve unusual and found conditions on the Highline.

7.   Preserve wild opportunistic landscape by enhancing existing plant species.

8.   Preserve industrial presence of the Highline at street level.

Current Highline Park

Ben Samson

Mostly, the designers sought to preserve the unique quality of a self-sown landscape and accentuate the structure’s industrial past. As I design Pittsburgh’s transportation system, I too am looking to build on the city’s industrial roots and explore the distinctive hilly landscape. The Highline teaches us that building on the uniqueness of a place can be achieved with simplicity and contemporary design ideals. It maintains the character of its past, yet is entirely modern and offers the hope of a brighter, greener future.

Sources:

http://www.thehighline.org/

Hazari, Patrick. Designing the Highline: Gansevoort St. to 30th Street. Friends of the Highline. New York, NY 2008.

Shaping the American Transit Landscape: A History of How We Got Here

Introduction

Cities are living histories that are constantly evolving. With nuanced technological changes and sweeping ideological reforms, every generation of urban planners, politicians and technocrats sees new possibilities for our urban centers. One factor of particular dominance in the molding of our cities is transportation, and as technologies evolved, the history of transportation has had a massive impact. Streets and transit-ways compose the majority of the public realm within cities, and thus are critical in the formation and maturation of the urban fabric. Furthermore, cities present unique and challenging situations and opportunities for transportation, often leading to the evolutions of new transit technologies. Therefore, cities play a major role in the evolution of transit, and conversely, transit plays a major role in the evolution of cities. This cause-effect cycle is what has shaped America’s urban transit landscape.

Part 2 of the Transportation Research Board’s “Transit Capacity and Quality of Service Manual” (TCQSM) discusses current modes of public transit in the U.S. while the first three chapters of Alan Black’s Urban Mass Transportation Planning discuss the importance, impact and history of U.S. transit, explaining how the current transit modes evolved. While Black lays a solid groundwork for understanding the history of transit in America (both technologically and politically), the text only covers the history through around 1990. On the other hand, Part 2 of the TCQSM explains recent (2004) trends in transit, examining data from the 2000 census. While there is a slight gap, taken together, these two readings compose a thorough understanding of the evolution of transit in the United States. When examining a city, as I am examining Pittsburgh throughout my thesis work, these texts not only offer an in-depth examination of transportation history and its current transit capabilities, but they also hint at a possible future.

Public Transit Ridership

TRB, 2004

Current Riders and Transit

Part 2 of the TCQSM asserts that there is a dual role of public transit: to offer transportation both to “choice riders” and to “captive riders.” Choice riders are those “who choose to use transit for their trip-making even though they have other means of travel, in particular, a motor vehicle” (TRB, 2004). The TCQSM explains that these riders choose transit for many reasons including saving money, avoiding traffic, using their travel time productively and helping the environment. The “captive riders” use transit for basic mobility and are those who cannot drive because of their age or “physical, mental or financial disadvantages.” Black asserts that these captives (which he calls “transportation disadvantaged”) include 11.5% of households and over 20% for center city dwellers. While it is extremely important to serve both types of riders, the “choice riders” dominance and heavy flow (during peak hours) tend to push transit systems to greater levels. In analyzing transit riders, TCQSM outlines the basis of solving America’s transport problems. The TRB looks to Transportation System Management solutions that focus on moving persons and not just vehicles. By readjusting our thinking, and focusing on riders, the benefits of public transit become even more attractive in transportation planning. By focusing on whom transit serves, we can understand how to best serve them.

The TCQSM also analyzes the many modes of transport currently used to serve these riders. Current transit modes discussed in Part 2 of the TCQSM include the major modes of transit like buses and rail, as well as some less common forms like ferries and funiculars (See exhibit 2-3). Surprisingly, due to Pittsburgh’s aggressive topography and its three rivers, most of these transit modes are relevant to the city and offer possible solutions for its transportation future. Pittsburgh public transit is dominated by buses much like greater America, where buses make up 62% of passenger transit (TRB, 2004). However, the focus of my thesis deals primarily with BRT and LRT systems in the city. The TCQSM examined both of these systems in Pittsburgh (as well as many other cities), implying the city’s importance regarding these modes of transit. Because of the three busways in Pittsburgh, the city is especially important to understanding and planning future BRT systems. Though I will compare the busway and light rail systems later in this class, the TRB implies that both of these modes are viable for the city and expansion of them offers solutions for future transit within Pittsburgh (See exhibits 2-14 and 2-24).

Busway Peak Traffic

TRB, 2004

LRT Systems

TRB, 2004

Transit History’s Impact

It is important to place current transit modes into the historical context of urban transportation. In the first three chapters of Urban Mass Transportation Planning, Black outlines the technological and political history of transit in America. He recounts the humble beginning stages of transit (horse-drawn Omnibuses and Street Railways), which were born from private sector entrepreneurs. Rather quickly, newer technology led to the dominant forms of transport we have today. Black emphasizes that the evolution in transit in the 19^th century was a very rapidly changing scene, where in “75 years, the country went from the horse-drawn omnibus to the motor bus and electric subway trains” and that most of the current technology in transit was being used by 1900 (Black, 1995).

This burgeoning period has shaped our cities. The development of each mode of transport has given a defined character to its urban environment. Trolleys and streetcars still offer a taste of historic character in cities like San Francisco while continuing to serve the public. In Pittsburgh, the two remaining funiculars (known as inclines) retain the memory of the city’s past (there used to be 15 inclines in the city). The effect of past history of public transit systems goes beyond the physical remnants still found in cities, but also includes the evolution of the city’s fabric itself. In Black’s conclusion of chapter 2, he reflects on how the history of transit has affected the growth of major cities in our nation:

“One can speculate on what would have happened if the automobile had been invented earlier. If it had preceded the electric streetcar, instead of coming later, perhaps U.S. cities would never have developed the centralized, high-density form characteristic of the late 19^th and early 20^th centuries. We’ll never know.” (Black, 1995)

Though we cannot be sure, it is safe to assume that focusing on the automobile, rather than more tightly woven forms of transport, would have created less centralized urban fabrics. For example in Brasilia, the capital of Brazil, which was designed with automobiles as the dominant form of transportation, the city is completely spread out, with a very loose urban fabric. Thankfully, the automobile was not widespread until after the bones of our older American cities were already in place.

Perhaps the only historic element more important than technological advancements in shaping our transit systems is political influence. Black’s examination of past transit legislation offers insight to why and how the transit systems evolved the way they did. Originally, private individuals owned public transport, but as the systems grew and started to fail, government began controlling ownership. Transit systems were seen as indispensible to urban life and therefore could not be left to fail. First, capital costs were subsidized by the federal government, but by 1974, the overwhelming burden of operating costs also began to be federally subsidized as well.

Black explains that certain presidential administrations affected transit in the U.S. through acts of legislation and budgets. The federal government largely affects Pittsburgh’s Port Authority (PAT) because of the Pennsylvania Commonwealth Act 76 of 1986, which states that Pennsylvania’s cities must have balanced budgets for their transit authorities. According to Steve Bland, the PAT’s CEO, the city is currently facing massive budget shortcomings and must “cut service and increase fares” to cover rising costs (Budget 2011). There is little room for capital investments without the aid of the federal government and thankfully, the stimulus package has invested the necessary funds for the current “North Shore Connector.” Many cities around the U.S., faced with budget crises much like Pittsburgh’s, rely heavily on federal funding for the expansion of their transportation systems. The timing and quantity of such funding greatly affects how the transit is built.

Conclusion: Planning Future Transit

Because we understand transit’s past, we can better plan for the future. The importance of transportation in shaping a city is paramount, and every decision we make must be carefully examined and planned. Today, planning has become an integral part of the transportation systems in our cities. The federal government formally recognized transportation planning in the Hayden-Cartwright Act of 1934. Black extols the 1991 Intermodal Surface Transportation Efficiency Act (ISTEA) for mandating all urbanized areas with 200,000 or more inhabitants to have 20-year transportation plans that focus on energy conservation, land use, intermodal access and social, economic and environmental effects. As I investigate expanding Pittsburgh’s public transportation systems, it will be critical for me to follow the tenets outlined in the ISTEA in order to better serve transit riders and the greater metropolitan community.

Transit Trends

Black, 1995

Trends in Black’s Urban Mass Transportation Planning show that public transit in the U.S. has been slowly and steadily rising since the 1970’s (See figure 2-9).  The TRB’s data confirms this rise as 9.4 billion annual unlinked passenger trips on public transit were recorded in the 2000 U.S. census (See exhibit 2-3). Furthermore, in the first quarter of 2010, APTA estimates nearly “2.5 billion trips were taken on public transportation,” which would total 10 billion trips for the year (McKendrick, 2010). Moving forward, as cities and transit systems expand, it seems clear that transit will play an ever-increasing role in our urban centers, perpetuating the cause-effect cycle that shapes America’s cities and their transportation systems.

References:

Black, A. Urban Mass Transportation Planning. New York: McGraw Hill, 1995.

McKeendrick, Joe. “Public transportation ridership weathers slow economy, tight budgets.” Smart Planet. June 7, 2010. Accessible online at:

        http://www.smartplanet.com/blog/business-brains/public-transportation-ridership-weathers-slow-economy-tight-budgets/7630

Port Authority of Allegheny County. “Operating and Capital Improvement Budgets: Fiscal Year 2011.” 2010. Accessible online at: http://www.portauthority.org/paac/portals/Capital/2011Budget/FY2011BudgetBook.pdf

Transportation Research Board: “Transit Capacity and Quality of Service Manual (TCQSM), 2^nd Edition.” TRB Publications, 2004. Accessible online at:

http://www.trb.org/news/blurb_detail.asp?id=2326

Riding the T

Downtown Light Rail Map

Pittsburgh Port Authority

This past week, I rode the “T” for the first time. I started in Station Square and headed north into the city, exiting at the Wood Street stop, the last station currently open. It was a convenient way to get into downtown from across the river, however, because of the limited number of open stops, it didn’t get me very far. I have travelled on many public rail systems in my life: Rome, London, Paris, NYC, DC, Zurich, Boston and Dallas to name a few, so it was hard not to compare Pittsburgh to those other systems.

T Map

Pittsburghtransit.info

Examining the map of the current system, it is clear that the T is mostly a commuter rail. After the Station Square stop, there are only 5 downtown stops and 2 more stops under construction on the North Shore. Conversely, there are 56 stops outside of the city reaching as far as the Library and South Hills Village!

Station Sq stop

Ben Samson, 2011

It was mid afternoon, off-peak hours, when I rode the T last week, and it was still relatively busy. Here is a look at some of the details of my trip.

 You have to walk across the tracks at the stop to go north. The yellow line is where the trains stops in order not to hit pedestrians. Remember to look both ways!

Ben Samson, 2011

 The tracks- which you can stand on

Ben Samson, 2011

Platform

Ben Samson, 2011

The rail cars have 2 cars

Ben Samson, 2011

LED display

Ben Samson, 2011

Nice waiting area

Ben Samson, 2011

The electric system

Ben Samson, 2011

From the Station Square stop, we took the T north into the city, passing First Street station, Steel Plaza and we exited through Wood Street station. Here are some images of the train we entered. It felt a little old- clearly felt like the 80's when the system was built, but it was very clean.

 Train interior

Ben Samson, 2011

The Rail Map inside the trains. Note that it doesn't match the maps in the stations or maps online.

Ben Samson, 2011

Blue linoleum floor.

Ben Samson, 2011

Matching seat fabric

Ben Samson, 2011

Train interior

Ben Samson, 2011

Here is a look at the Wood St station. It really felt a lot more substantial. The polished granite was a nice touch throughout the station. Also, the Steel Plaza station was very large and felt very metropolitan.

Wood Street platform

Ben Samson, 2011

 Wood Street escalators- fairly packed

Ben Samson, 2011

 Wood Street escalators

Ben Samson, 2011

 Wood Street station. Not as professional as some other systems.

Ben Samson, 2011

Overall, I enjoyed exploring the T. It seems to be serving its purpose well, though is a little bit unrefined. It is clearly not a big presence in the city and if it took me almost 24 years of living in Pittsburgh to actually ride it, then it must not have a wide ranging purpose. The trip itself was quick, and though we only went a couple of stops, i certainly got a slice of the commuter life.

The trains were comfortable--also small-- and very clean. The materials were old, but not worn. There was a sense that it hadn't been updated in a while, but in no grave need of it.

Some of the logistics were not very user friendly. The signage was a mess. None of the maps matched, and there was no real sense of identity to the system. We bought tickets from a teller at the Station Sq stop and we needed exact change. The stations in Downtown were clearly more substantial than at Station Sq, which added to some of the discord.

However, none of these setbacks seemed to greatly affect the service which I found to be comfortable and efficient. Perhaps it is different during rush hour, but it the T seemed to live up to the Pittsburgh reputation of friendliness. It might have been the most amicable, and least pushy light rail I've ever used!

Sources:

http://www.pittsburghtransit.info/lrt.html

http://www.portauthority.org/PAAC/CustomerInfo/BuswaysandT/LightRailTransitSystem/tabid/186/Default.aspx

The Image of the Steel City

In Kevin Lynch's "The Image of the City," he lays out a plan for understanding the built environment of a city based on human perception of the physical form of cities. Basically, he examines how the urban fabric is imprinted in our minds and accessed in our memories.

In this post, I am going to look at a more specific way a city imprints its "image" into our minds. Pittsburgh's historic image has imprinted itself not only in our memories, but also on the physical fabric of the current post-industrial city. It is this historic image of the smokey steel mills that has defined Pittsburgh, and even now in the 21st century, with the soot gone, the city's industrial image remains prevalent.

Smokey City

Eugene Smith, 1955

In 1955, photographer Eugene Smith captured Pittsburgh's industrial spirit in his work "Dream Street, W. Eugene Smith's Pittsburgh Project." In this three-year-long project, he portrays the city as an industrial dynamo, burgeoning in its prime. The city was the backbone of the nation's steel industry and Pittsburgh steel was used to build every great American urban center.  Here is a look at some of Smith's famous pictures of the Steel City.

Dance of the Flaming Coke

Eugene Smith, 1955

Pittsburgh, Steel Worker

Eugene Smith, 1955

US Steel, Pittsburgh

Eugene Smith, 1955

Pittsburgh Steel Mill

Eugene Smith, 1955

Today, the memories that Smith captured endure. This past week, I went around town searching for some of the remnants of Pittsburgh's industrial past, and was shocked at the extent of my findings. Aside from the textures that are imprinted with the soot from the steel mills (see Pittsburgh Textures post), here are a few examples of the historic image of the city.

Smokestacks at the Waterfront

Jeff Swensen for the NY Times

Mural, An Homage to Eugene Smith

Washington Post.com

Bessemer Court, Station Sq.

Ben Samson, 2011

Nine Mile Run Slag Heap

Nature in the Post-Industrial Landscape

Blowing Machine, South Side

Ben Samson, 2011

 The Steelers

Kingdom-Biz.net

Heinz Plant, North Side

Marantzer, Flickr, 2008

US Steel Tower, Tallest Structure between NYC and Chicago

GlassSteelAndStone.com

Though the steel industry is gone, its presence remains ubiquitous. It is something that the city cherishes, and owes its character. Pittsburgh remains a blue collar town (at least in feel). The people embrace their working-class roots. This history is a source of pride.  It is evident in the name of the NFL team, the Steelers, who are the cultural lifeblood of the city. It is seen in Pittsburgh's skyline, in the US Steel tower. Old machinery and smokestacks act now as sculptures and cultural landmarks. Hiking and Biking paths mingle along old slag heaps.

One can find instances of the historic image of Pittsburgh in all of the five elements that compose the mental maps of cities, according to Lynch. It is found in Pittsburgh's paths, edges, districts, nodes and landmarks.

In designing any form of public transformation, a project that could vastly reshape the "image of the city," it is critical to consider Pittsburgh's industrial history and its historic image. The system must be respectful of this heritage and should coalesce with its deep cultural impact.

Sources:

Lynch, Kevin. The Image of the City, MIT Press Cambridge, Mass. 1960.

Stephenson, Sam. Dream Street, W Eugene Smith's Pittsburgh Project. W W Norton and Co. 2001.
